Wire Saw Machine

Diamond Wire Saw Machine

Wire Saw Machine Manufacturers

Wire Saw Machine, the fastest diamond wire cutting machine on the market is a high productivity product for the dimension stone industry. This provides better stability and accuracy in quarrying. Vardhman Machinery Equipments Pvt. Ltd. supply high-quality diamond wire cutting machines and exact match for Indian quarrying conditions. These machines create a perfectly smooth face of the block and can cut both vertical and horizontal and close to ground level to get an even bottom. Wire Saw machines are widely available in various specifications and dimensions of 20hp, 60hp and 75hp categories.

Concrete is one of the hardest materials to cut through and traditional cutting techniques just don't work with concrete. Our Wire saw machine is among the newest range of machines that are capable of cutting through Concrete with ease. This type of machine also known as the Optima Wire saw machine is essential in works like skyscraper construction, mining, or any other heavy-duty work. How does a wire saw machine work? Well, let’s say one has a huge boulder or block of concrete they need to place at a certain location with a certain angle and with a certain weight. For such specific purposes, there might come a time where one needs to cut through the concrete, so firstly they’d dug a small hole through the concrete through which our wire passes. Then the Optima Diamond Wire Saw is responsible to initiate the cutting. The wires, in response to the motor generating high power, move very fast over the surface of the material that needs to be cut. With the friction, the wire causes against the surface of the block, it starts to dig into its surface inch by inch. The friction may damage the wire or even the block that needs to be precisely cut thus water is used to soften up the blow. Water forms a layer between the chain and the surface of the block bause of which less heat is generated and the procedure takes place without any mishaps. At Vardhman Machinery Equipment we deal with all sorts of parts and elements required for drilling, mining, and construction purposes. All sorts of wire saw machines that are needed in various industries for various procedures are available at our own outlet. The saw can cut through concrete and rock with much ease. These are designed to be used in vigorous procedures and are capable of significantly decreasing the work of the layman. The cutting that would usually take days and multiple workers to get done now can be done in just a few our with the least amount of human intervention required. At Vardhman Machinery Equipment Private limited, we provide only the products that are highly efficient, durable, and are among the best, the industry has to offer. We also deal with a lot of other products required in various construction and mining activities. At Vardhman Machinery we not only provide you with a product we also give you assurance and trust.


Diamond Wire Saw Machine 20 HP

Main Body Includes:

  • 20 HP AC Electric Motor - Make "SIEMENS /HAVELLS”
  • Complete Travelling Track Of 14 to 16 feet
  • DC Motor 1Hp Make “Elmo"
  • Low Cost Maintenance
  • Heavy Body Frame
  • Aluminum wheel 640 mm with Rubber Ring

Electrical Control Panel Specifications:

  • Control Panel Board : Powder Coated Body
  • Control Panel : Heavy electrical Panel With BCH Plug , Socket & contactor
  • Control Panel cable : 10 Mtr

Diamond Wire Saw Machine 60 HP

Main Body Includes:

  • Main A.C. Electric Motor - 45KW/ 60 HP Make “SIEMENS/ABB”
  • D.C. Electric Motor 1440 RPM : 1 HP Make “Elmo"
  • Complete Travelling Track : 3 meter 1 Nos and 2 meter 2 Nos
  • Heavy DC Gear Box
  • Heavy Body Frame
  • Main flywheel : 790 mm Diameter with Rubber Ring
  • Total Weight : 1900 Kg (Approx.)

Electrical Control Panel Includes :

  • Control Panel Board :Powder Coated Body
  • Control Panel : 10 Mtr
  • Heavy Electrical Panel with BCH Plug, Socket & Contactor

Optional :

  • Stand for Guide Pully
  • Bolt Cutter
  • Crimping Tool

Diamond Wire Saw Machine 75 HP

Main Body Includes:

  • Main A.C. Electric Motor 1440 RPM - 56KW/ 75 HP Make“SIEMENS/ABB”
  • D.C. Electric Motor 1440 RPM : 2 HP Make “Elmo"
  • Complete Travelling Track Of 07 Meter (3 Meter: 1 Nos, 2 Meter: 2 Nos )
  • Heavy DC Gear Box
  • Heavy Body Frame
  • Main flywheel : 800 mm Diameter with Rubber Ring
  • Total Weight : 1900 Kg (Approx.)

Electrical Panel Includes :

  • Control Panel Board :Powder Coated Body
  • Control Panel : 10 Mtr
  • Heavy Electrical Panel with BCH Plug, Socket & Contactor

Extra Features :

  • Energy Meter -Indicates electricityconsumption
  • Hour Meter - Machine RunningTimeMain Body includes:
  • ELR (Earth LeakageRelay)

Optional :

  • Guide Pully : 14 Inch (2 Nos)
  • Bolt Cutter
  • Crimping Tool
